Strainer Valve Jacket Insulation
| Bulk Quantity Discount | |
|---|---|
| Minimum Quantity | Discounted Price |
| 30+ | 2% Off |
| 60+ | 5% Off |
Request a Quote
Our team is happy to fulfil custom orders, offer special bulk discounts you cannot get from the website. Please get in touch today to discuss your needs.
Valve jackets are the best way to insulate strainers. Since the jackets contain mineral wool, they give superior insulation. They also improve workplace safety and help make your building more energy-efficient.
Here’s how:
- Manufacture: The thermal insulation jackets that we supply here at Buy Insulation Online are made with top-quality silicone glass cloth, that ensures a neat and smooth finish every time. The cloth is sewn around 50mm Rockwool which has low thermal conductivity and helps to restrict heat loss in strainers. Valve covers also have velcro straps and pull cords that give airtight insulation around the strainer valves. They also protect valves against dirt, dust and other impurities, thus increasing the service life of the valves.
- Thermal Insulation: Valve covers contain mineral wool with low thermal conductivity, meaning they restrict heat loss in valves. It helps save energy and money and also decreases your carbon footprint. The pull cords and velcro strap make installation easy. Furthermore, they ensure that valve covers fit perfectly around strainers, leaving no gaps, and thus no way for heat to escape.
- Safer Workplace: Valve covers help protect your staff from direct contact with the hot surface of the strainer valve. Not only that, but since the valve jackets restrict heat loss, cases of condensation and sweating will also be reduced. As a result, workplaces will no more have small pools of water that can easily lead to slips or accidents, injuring personnel. Hence valve covers give way to a cleaner and safer work environment.
- Easy to Maintain: As mentioned earlier, valve covers can be easily installed around three-way valves. They can just as easily be removed for maintenance purposes. Unlike traditional, rigid insulation, valve covers are not damaged when they are removed or re-installed.
Product Specification:
- Product Sizes: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm, 65mm, 77mm, 100mm, 125mm, 150mm, 200mm, 250mm and 300mm.
- Colours: Standard grey, silver, white and black.
- Type:
- External jackets: For external use, valve covers for the strainer valve covers have an external, waterproof PVC cloth whilst their inner layer is made of silicone glass cloth
- Internal jackets: Insulation jackets for strainer have silicone glass cloth on both sides.
Key Features:
- Valve covers are flexible, lightweight and easy o install.
- Provides fully sealed insulation to strainer ball valves to avoid any airborne contamination and possible harm to personnel.
- Cost-effective and convenient.
- Insulated valve jackets improve workplace safety.
- Prevents issues like condensation and sweating in strainers.
- Made with high-quality glass cloth to easily fit the strainers.
- The valve jackets are made from silicone glass fibre cloth sewn with around 50mm of insulation.
- The jackets have velcro flaps and pull cords fixings to ensure superior insulation.
Applications:
- Valve jackets are designed to closely fit around strainer ball valves to maximise insulation and prevent heat loss.
Product Details:
- Service Temperature: -20°C to 220°C
- Insulation: 50mm Rockwool
- Cloth: Silicone glass cloth/ PVC
Note:
- All Valve jackets are made to order, No returns, refunds or exchanges will be applicable. If you are unsure of the size, please email us a picture of the valve and its dimensions for our experts to access and make the valve covers suitable for your application. We will assist you in any way we can.
- Lead times for screwed valve covers within the UK: 1-10 units: 5-7 working days, Anything above that, please email us for the lead times.
| Insulation Type | Valve Covers |
| Cloth Material | Silicone glass cloth / PVC |
| Insulation | Mineral Wool |
| Suitable for | Strainer valves |
| Colours Available | Standard Black, Silver and Standard Grey |
| Standard Sizes | 15mm, 20mm, 25mm, 32mm, 40mm, 50mm, 65mm, 77mm, 100mm, 125mm, 150mm, 200mm, 250mm and 300mm. |
| Service Temperature |
-20 °C to +220 °C |
| Delivery Terms | |
|---|---|
| Order Value (Excluding VAT) | Delivery Charge (Excluding VAT) |
| Above £390 | Free delivery |
| £50 - £390 | £15 |
| Up To £50 | £ 8 |
Product: All valve covers are made to order and NON-REFUNDABLE. If you are unsure of the size, please email us a picture of the valve and its dimensions for our experts to access and make the valve covers suitable for your application. We will assist you in any way we can.
We welcome you to share information on the pipe insulation thickness and images of your application along with the order to help us get your requirement correctly.
If you require a quote for these valve jackets, please do email us with your requirements
Returns and cancellations:
You are free to cancel your order before we confirm your order via email. Once an order confirmation email is sent, cancellations, returns and refunds will not be acceptable.
Additional information:
- We do site surveys and supply valve covers or we can only survey your premises. If you would like a site survey, kindly email us your site address or fill the contact form above.
- The prices for the chilled/cold water valve jackets may differ from the ones displayed on the website. Chilled/cold water valves usually need to be wrapped with a vapour barrier, which would increase the jacket size and cost. If you need chilled/cold water valve covers, please mail us your requirements and we will send you a quote for your order.
- We also make valve covers in red, blue and green colours. If you have any such requirements, please get in touch with us.
Product Features
- Thermal insulation jackets are available in sizes ranging from 15mm to 300mm.
- They are also available in colours: standard grey, black and silver colours.
- Valve covers for strainers help improve workplace safety.
- Made with high-quality silicone fibreglass, they give a superior finish when used to insulate strainers.
- Valve jackets can be used in temperatures as high as 220°C.
- They give superior thermal insulation to stainers
- Valve covers prevent sweating and condensation, thus reducing accidents in the workplace.
- All Valve jackets are made to order. NON REFUNDABLE
You May Also Like
Shop now. Pay later.
We support Clearpay. With Clearpay you can Pay it in 4 interest-free instalments.
Subject to credit approval. T&C apply.
Shop now. Pay in 30 days.
We accept Klarna. Pay up to 30 days later. No interest. No fees, when you pay on time.
T&C apply. Credit subject to status.
Customer Reviews
“ I ordered one first to see how the product performs. back again to order som more. Thank you. ”Ben R.
Verified Buyer
“ quicker turnaround that any company I have dealt with. Good going guys!”Alex A.
Verified Buyer
“ Super staff. they went above and beyond to get my order perfect”Kate H.
Verified Buyer
“ better lead times and top-quality product. goos stuff thank you very much”Matt C.
Verified Buyer
“ Good product, just hat i was looking for”Daniel W.
Verified Buyer
“ this is our second purchase with this company. quality product and good prices too.”Olivia H.
Verified Buyer
“ faster turnaround and better product. Thank you”Peter L.
Verified Buyer
“ We needed 20 weatherproof jackets for valves outside. Ordered one first for testing. It was just wha...”Theo F.
Verified Buyer
“ I have ordered this to protect the outdoor tap against frost and cold weather. I'm happy with my pur...”Greyson Y.
Verified Buyer
“ Faster turnaround, even on a large order. Good stuff”Arthur R.
Verified Buyer
“ Easy to fit. Just a drawstring Looks like it stayed on over the winter. Very pleased with it.”Silas
Verified Buyer
“ Bought to protect outside tap from frost and cold weather Strong material Fitted in minutes Pleas...”Emily
Verified Buyer
“ jackets were perfect. order came sooner than expected. good service”Oliver J.
Verified Buyer
Our Customers Include
Strainer Valve Jacket Insulation
Strainers play an important role in the H&V system. They help filter out impure, foreign particles in the pipeline. So it is critical to insulate strainer valves and protect them in any way possible.
Valve jacket insulation protects strainers - both screwed and flanged- from damage, heat loss and much more. At Buy Insulation Online, we stock top-quality valve jackets from strainers, at a low cost. These are made in standard grey, standard black, white and silver colours.
We stock these insulation jackets in sizes ranging from 15mm to 300mm. If you are unsure of the right size for your application or need custom-made strainer valve covers, drop us an email or call us, and we will be happy to help you. We also do job site surveys for valve insulation jackets.
Now, let's look into the stainer valve jackets insulation, in-depth:
What are strainer valves?
As mentioned above, strainer valves help filter out extraneous material from pipelines. The versatility of strainers makes them essential to the health and security of the system they are utilised in. These valves ensure the safe functioning and durability of other components of the plumbing system including, pumps, control valves etc
Why insulate Strainer valves?
Strainers help filter out the unwanted materials in your plumbing which in turn ensure smooth functioning of other plumbing components. Therefore it becomes critical to protect such an important component from any kind of damage and harmful environmental conditions
Also, without insulation of their own, strainer valves can be a point of heat loss/gain for the liquid within. By insulating them, you not only restrict heat loss but also prevent condensation or sweating of strainer valves.
Valve jackets can help you do both of these. They are flexible, removable valve covers that perfectly fit around strainers for airtight insulation. They protect them from heat loss, condensation/sweating and external damage. This converts to a healthier plumbing system and lesser energy bills.
Is strainer valve jacket insulation worth it?
Earlier, strainers were insulated with hard, rigid traditional insulation. The insulation materials used offered good thermal insulation but were difficult to maintain.
Every time strainer valves needed maintenance, the rigid insulation around them was removed, sometimes harming both the insulation and the stainers in the process. This would increase the time for maintenance. Plus, if the insulation was to be harmed in the process and considered unfit for re-installation, then the whole time strainers would be without any insulation leading to a waste of energy and money.
Valve jackets are a smart way and innovative way to insulate strainers. They can be removed and just as easily reinstalled without harming the insulation or the strainers. Valve covers reduce maintenance time, saves money and protects the strainer. Valve jackets are definitely worth it.
How do valve covers work?
Valve covers are made of two main components. The silicone or PVC coated fibreglass cloth and mineral wool insulation. Each strainer valve jacket has about 50mm mineral wool insulation in it. Mineral wool has low thermal conductivity, and hence restricts heat loss/gain in strainers.
The fibreglass cloth is approved by the required regulatory bodies for use in plants, factories etc. They protect personnel and valves from burns and damage, respectively.
Does valve jacket insulation stop condensation/Sweating?
Yes. When you insulate a strainer valve with a valve cover, you restrict the heat loss or gain. Valve jackets also cover the valves from all sides, giving airtight insulation.
So, the strainers are not in direct contact with the surroundings, and hence the temperature difference between the two is lower. Condensation happens when there is a significant temperature difference between two surfaces. Therefore, by covering the strainers and by restricting heat loss/gain in them valve jacket insulation prevents condensation and sweating in valves.
How do valve covers improve working efficiency?
When strainers are left uninsulated they lose/gain heat, condense or sweat, leading to the formation of tiny pools of water. An employee could slip due to these pools leading to accidents and mishaps in the workplace.
Also, valve covers protect personnel from coming in direct contact with the hot surface of the strainers. If the strainers are not covered properly, it could cause burns when the employee comes in direct contact with its hot surface.
Strainer valve jacket insulation makes a workplace much safer and therefore, efficient.
Where can I buy the Stainer valve jacket Insulation Online?
You buy this valve covers online right here at Buy Insulation Online. We stock them in standard sizes and if you are unsure of the size you need, we are just a call or email away.
How to choose the size of a Strainer insulation jacket?
The size of the valve cover will depend on the size of the pipe your strainer is on. For example, if the strainers are on a 32mm pipe, then the strainer valve cover you need is 32mm.
Another important information we need when we make these jackets is the thickness of the pipe lagging on these pipes. The valve made needs to cover the entire set-up.
How to fit the strainer valve jacket insulation?
Free the strainer valve of any dirt with a dry cloth. Just wrap the valve cover around them, and secure it using the velcro straps on the valve jackets. Draw the pull cords to ensure airtight insulation.
Insulating strainer with valve jackets is the best way to protect them from heat loss and damage. If you need any help with your purchase, we are just a phone call away.
