Product Details
Available with / without foil facings
| Thickness | Length | Width | Coverage per board | Specifications | Size |
| 18mm | 1200mm | 600mm | 0.72 Sqm |
‘CNC Routed XPS – ‘Universal’ Design with Radius return at one end of boards & 3 x cross returns. |
12mm @ 150mm c/c |
| 20mm | 1200mm | 600mm | 0.72 Sqm | CNC Routed XPS – ‘Universal’ Design with Radius return at one end of boards & 3 x cross returns | 16mm @ 150mm c/c |
ResoTherm XPS-R 300 represents the pinnacle of Resonate's range of high quality underfloor heating solutions. These underfloor heating insulation boards are engineered from high density extruded polystyrene to provide exceptionally high performance for all underfloor heating systems. The board's robust nature makes it ideal for new build and refurbishment projects, and are ideal for all types of developments including offsite, residential and commercial applications. A foil-faced version of the boards is also available, offering excellent heat transfer
Key Features:
- These underfloor heating baords offer high thermal performance, with an option of foil facing.
- Have ultra high compressive strength and high heat transfer
- Suitable for all types of 12mm / 16mm UFH pipes.
- Can be used as part of an acoustic system on separating floors
- ResoTherm XPS-R 300 is 1.2M long and 600mm wide.
- Available in 2 thicknesses - 18mm & 20mm (Suitable for 12mm and 16mm pipes)
- Features CNC grooved channels for UFH pipes to be installed.
- It provides exceptionally high performance for all underfloor heating systems
| Product Name | ResoTherm XPS-R 300 |
| Material | High-Density Extruded Polystyrene (XPS) |
| Fire performance | Euroclass E. |
| Compressive strength | 300 kPa. |
| Thermal conductivity | 0.034 W/mK. |
| Thickness | 18mm, 20mm |
| Application | Underfloor Heating, Acoustic System on Separating Floors |
| Colour | Purple |
| Delivery Terms | |
|---|---|
| Pallet Charges apply to deliveries. £65 +VAT per pallet |
