Proctor Wraptherm Airtight Membrane is an innovative, high-performance composite insulation and airtightness solution developed by Proctor Group for refurbishment and retrofit applications. This product combines a 10mm Spacetherm insulation blanket bonded to the face of Wraptite vapour permeable, airtight self-adhesive membrane, providing an innovative system that enhances both thermal efficiency and building airtightness.
Designed for use on the internal face of existing façades and wall constructions, Wraptherm helps reduce thermal bridging while creating a continuous airtight layer. This self-adhered membrane forms a durable seal against unwanted air leakage, helping to improve energy performance and occupant comfort.
Unlike traditional air barrier systems, Wraptherm remains vapour permeable, allowing moisture vapour to pass through the construction while maintaining an airtight envelope. Its vapour-open yet airtight design helps support healthy building fabric performance and moisture management.
Its ultra-thin profile makes Wraptherm ideal for projects where space is limited but thermal upgrades are required. By combining insulation and airtightness in a single product, Proctor Wraptherm provides an efficient solution for improving thermal performance and reducing heat loss in refurbishment projects.
Key Features
- High-Performance Composite System: Combines Spacetherm insulation with Wraptite airtight membrane technology.
- Improves Airtightness: Enhances building airtightness by creating a continuous air seal. Single product airtightness and thermal bridging solution
- Vapour Permeable Membrane: Allows moisture vapour movement while remaining airtight.
- Self-Adhesive Installation: Features a self-adhesive membrane for fast application to suitable substrates.
- Enhances Thermal Efficiency: Improves overall thermal performance of refurbishment projects.
- Thin Insulation Solution: 10mm Spacetherm insulation provides high thermal performance with minimal thickness.
Applications
- Internal façade refurbishment projects.
- Retrofit insulation upgrades.
- Façade Retention projects
- Proctor Wraptherm is supplied in 2.4mm Long, 1.2mm wide and 11.5mm thickness.
- Composite system combining 10mm Spacetherm aerogel insulation with Wraptite vapour permeable, airtight self-adhesive membrane.
- Use of Wraptherm provides increased airtightness levels combined with a reduction in thermal bridging.
- Designed for internal application to existing façades and wall constructions.
| Product Type | Insulated Breather Membrane |
| Product Code | Wraptherm |
| Brand | Proctor |
| Length | 2.4M |
| Width | 1.2M |
| Thicknesses | 11.5mm |
| Thermal Resistance | 0.667m2 K/W |
| Installation Temperature | -10°C to +60°C |
| Water Penetration | Class W1 |
| Service Temperature | -40°C to +100°C |
| Order Quantity | Delivery Charges |
|---|---|
| 1 - 70 Sheets | £140 +VAT |
| Above 70 Sheets | Free Delivery |
